Saponification Process Flow Diagram: |
Soap Process Flow Diagram: |
|
|---|---|---|
| [ Oils & Fats ] + [ Caustic Soda (NaOH) ] │ ▼ ┌───────────────────────────┐ │ 1. SAPONIFICATION │ ──► [ By-product: Glycerin ] │ (Heating & Chemical Reaction)│ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ Liquid Soap Base │ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 2. VACUUM DRYING │ ──► [ Evaporated Water / │ (Instant Flash Evaporation)│ Steam ] └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ Solid Soap Base │ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 3. PLODDING & EXTRUSION │ │ (Mechanical Pelleting) │ └───────────────────────────┘ │ ▼ [ Final Soap Noodles ] |
[ Soap Noodles ] + [ Ingredients ] (Semi-finished) (Silicate, Perfume, Color) │ ▼ ┌───────────────────────────┐ │ 1. MIXING │ │ (Dosing & Blending Ingredients)│ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 2. MILLING │ │ (Three-Roll Mill Refining)│ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 3. VACUUM PLODDING │ ──► [ Trapped Air │ (Duplex Plodder Extrusion)│ Removed ] └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ Continuous Soap Bar │ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 4. CUTTING & STAMPING │ │ (Shaping & Logo Embossing)│ └───────────────────────────┘ │ ▼ ┌───────────────────────────┐ │ 5. PACKAGING │ │ (Wrapping & Boxing) │ └───────────────────────────┘ │ ▼ [ Finished Laundry Soap ] |
Technological Process of Soap Noodle Production
The advanced technological process of converting oils and fats into premium semi-finished soap noodles consists of three consecutive engineering stages.
1. Saponification Stage
First, high-quality animal and vegetable oils or fats react chemically with a strong alkali, such as caustic soda (NaOH). This intensive chemical conversion occurs under continuous heating and high-speed agitation. Consequently, a uniform liquid soap base is formed. In addition, the valuable by-product, glycerin, is efficiently separated and recovered through a specialized salting-out process.
Inputs: Blend of natural oils/fats + Caustic Soda (NaOH).
Process: Thermal heating, mechanical stirring, and chemical conversion.
Output: Refined liquid soap base alongside separated glycerin.
2. Vacuum Drying Stage
Subsequently, the liquid soap base is heated and sprayed directly into a heavy-duty vacuum dryer. Utilizing a low-temperature vacuum environment, the moisture evaporates instantly through flash evaporation. **Therefore**, the soap base undergoes rapid cooling and dehydrates into a premium solid state suitable for downstream molding. This advanced mechanism successfully protects the overall soap quality from thermal damage.
Mechanism: Spraying liquid soap into a high-vacuum chamber.
Flash Evaporation: Instant moisture evaporation at a significantly lower temperature.
Result: Rapid cooling and solidification into a high-grade solid soap base.
3. Plodding And Extrusion Stage
Finally, rotating blades scrape the solidified soap off the vacuum dryer walls. The scraped mass enters the powerful extruder, also known as a soap plodder, located at the bottom. **Moreover**, the machine mechanically compresses and extrudes the material through a dedicated matrix template. **As a result**, consistent, semi-finished soap noodles are generated, perfectly preparing them for subsequent milling and stamping.
Scraping: Rotating blades cleanly scrape the solid soap.
Pelleting: The plodder compresses and extrudes the mass.
End Product: Uniform, high-density soap noodles ready for final shaping.
Production Capacity Specifications
We provide flexible manufacturing solutions. Customers can select from our versatile batch options or high-capacity continuous lines based on factory demands:
| Saponification System Type | Available Production Capacities (Per Hour) |
| Batch Saponification Lines | 50 KG ~ 100 KG/H |
| Batch Saponification Lines | 300 KG ~ 500 KG/H |
| Batch Saponification Lines | 1000 KG ~ 1500 KG/H |
| Batch Saponification Lines | 3000 KG ~ 5000 KG/H |
| Continuous Saponification Lines | 10 Tons ~ 15 Tons/H |
Specifications
| Brand | JASUN |
|---|---|
| Batch capacity | 50–100 kg/h; 300–500 kg/h; 1000–1500 kg/h; 3000–5000 kg/h |
| Continuous capacity | 10–15 t/h |
| Inputs | Natural oils/fats + Caustic Soda (NaOH) |
| Process stages | Saponification (heating and chemical reaction); vacuum drying (instant flash evaporation); plodding and extrusion |
| Outputs | Liquid soap base and separated glycerin; solid soap base; uniform, high-density soap noodles ready for final shaping |
| Lead time | 30 days |
| Warranty | 12 months |
Power: 30–200 KW; workshop: (4–40) × 12 × 3.5 m; workers: 2–8 per shift. Power, workshop and worker figures are approximate and for reference only. Voltage 380V/220V, 50/60Hz can be customized; specific conditions are provided according to the target capacity.
Buying Guides
- What Capacity Soap Production Line Do I Need?
- Soap Making Machine Price: What Affects the Cost of a Production Line?
- What to Confirm Before Ordering a Soap Production Line
- Installation, Training & After-Sales Support
First, the questions below cover installation, recipes, lead time, payment, voltage, packing, references, and warranty. In addition, each answer is listed directly under its question. Furthermore, you can start with the question that matters most to you. Moreover, the answers are grouped in the order shown below. However, if you need more detail, you can ask for it in your inquiry. Therefore, please read the full answer before you decide. In conclusion, the list below is a quick guide to the most common topics. For example, the first answer explains installation support. In summary, the following questions and answers are here to help you plan. Finally, please use them as a starting point for your enquiry.
Also, the answers use short sentences for easy reading. Similarly, each question focuses on one topic at a time. In addition, the payment and warranty answers are stated in plain terms. Furthermore, the voltage and lead time answers are given without extra detail. Therefore, you can compare the answers quickly. Finally, please keep these answers with the specification table above. Moreover, the list is arranged from installation to warranty. In short, the section below is a quick reference.
Frequently Asked Questions
1. Do you help with installation in Africa?
Yes. We can send an engineer to your factory in your country for installation guidance, or guide your team remotely. For an on-site visit, the buyer covers the engineer’s travel expenses and salary.
2. Do you provide soap recipes?
Yes, we can provide soap recipes.
3. What is the lead time?
Usually one month.
4. What are the payment terms?
30% by T/T in advance, and 70% by T/T after production and before shipment.
5. What voltage do the machines use?
380V / 220V.
6. Does the line include a packing unit?
The packing machine is quoted separately. We can send you a price for the soap packing machine.
7. Can you provide references from customers who purchased your products?
We have exported our machines to over 50 countries, and we can send you bills of lading (B/Ls) from our previous exports.
8. Do you provide a warranty for the production line?
Yes, one year.
